COMPOSITION  100%Polyester
WEIGHT   5.6oz/yd²±5%
         190g/m²±5%
LIGHT FASTNESS ≥6Grade(ISO 105 B02)
OPENNESS FACTOR 8%
WEFT DEVIATION  ≤1%
ENVIRONMENT  GREENGUARD
FEATURE  UV Protection
FIRE RESISTANCE NFPA 701(USA)/BS 5867-2(U·K)

Gallery
Specifications
Print
  • Composition
    25% Polyester, 75% PVC
  • Openness
    3%
  • Width(s)
    98.4" (2.5m)
  • Length
    33 yd/roll (30m)
  • Weight
    12.24 oz/yd2 (415 g/m2)
  • Thickness
    0.024 in (.60mm)
  • Fire Classification
    NFPA 701, M2, BS 5867 Type B, CA Title 19
  • Fungal/Bacterial Resistance
    ASTM E2180, G21, G22
  • Acoustical Performance
    NRC 0.15 | SAA 0.15
  • Railroadable
    No
  • Cutting
    Knife, Crush, Ultrasonic
  • Welding
    248°F (120°C) to 284°F (140°C), Test First
  • Cleaning
    Lightly vacuum or wipe with dry cloth to remove dust. Spot clean with clean white pencil eraser or gently wipe with warm soapy water and damp sponge. If wet, leave shade down to dry completely. Avoid solvents or test them in inconspicuous area first.
  • Applications
  • Features
  • Certifications
  • Composition
    26% Polyester, 75% PVC
  • Openness
    3%
  • Width(s)
    98.4" (2.5m)
  • Length
    33 yd/roll (30m)
  • Weight
    12.24 oz/yd2 (415 g/m2)
  • Thickness
    0.024 in (.60mm)
  • Fire Classification
    NFPA 701, M2, BS 5867 Type B, CA Title 19
  • Fungal/Bacterial Resistance
    ASTM E2180, G21, G22
  • Acoustical Performance
    NRC 0.15 | SAA 0.15
  • Railroadable
    No
  • Cutting
    Knife, Crush, Ultrasonic
  • Welding
    248°F (120°C) to 284°F (140°C), Test First
  • Cleaning
    Lightly vacuum or wipe with dry cloth to remove dust. Spot clean with clean white pencil eraser or gently wipe with warm soapy water and damp sponge. If wet, leave shade down to dry completely. Avoid solvents or test them in inconspicuous area first.
  • Applications
  • Features
  • Certifications
